Description
Features intelligent BMS, LCD display, and Bluetooth for safe, convenient, and smart monitoring.
| Category |
Specification |
| Nominal Capacity |
3840Wh |
| Cell Specifications |
LiFePO4 |
| Cell Configuration |
4S1P |
| Charge Cut-off Voltage |
14.6V |
| Discharge Cut-off Voltage |
10.8V |
| Max Charge Voltage |
16V |
| Optimum Charge Current |
100A |
| Max Continuous Charge Current |
200A |
| Max Continuous Discharge Current |
200A |
| Battery Management System |
Over-voltage, Low-voltage, Temperature control, Overload and AC short circuit protection, Surge protection |
| Operating Temperature |
Charge temperature 0°C-60°C | Dischargetemperature -20°C -60°C |
| Cycle Life |
>5000 Cycles |
| Warranty |
3 Years |
| Dimension (W, D, H) |
387*206*282mm |
| Net Weight |
25kg |
| Shelf Material |
ABS Plastic Shell |
| Other Function (Optional) |
Bluetooth App |
| Screen |
LCD |
| Battery Type |
Rechargeable Lithium Iron Phosphate Lithium Battery |
