| Rated Input Voltage (VAC) |
208 / 220 / 230 / 240; L + N + PE |
| Voltage Range (VAC) |
90~280±3 (normal); 170~280±3 (UPS) |
| Frequency (Hz) |
50 / 60 (Auto Adaptive) |
| Rated Capacity (kVA) |
2.0 |
| Peak Power (kVA) |
2.4 |
| Output Voltage (VAC) |
208 / 220 / 230 / 240 |
| Power Factor |
1 |
| Output Frequency |
50/60Hz ± 0.1% |
| Switch Time (ms) |
10 (normal/UPS mode) |
| Wave Form |
Pure Sine Wave |
| Overload Capacity (Battery Mode) |
60s @ 102–110% load
10s @ 110–130% load
3s @ 130–150% load
0.2s @ >150% load |
| Max Efficiency (Battery) |
90%@12VDC |
| Parallel Quantity |
N/A |
| Solar Charger Type |
MPPT |
| Max PV Input Current / Power |
14A / 1000W |
| MPPT Operating Range |
20~100 VDC |
| Max PV Open Circuit Voltage |
125 VDC |
| Max PV Charge Current |
60A |
| Max AC Charge Current |
40A |
| Max Charge Current (PV + AC) |
100A |
| Battery Voltage |
12 VDC |
| Floating Charge Voltage |
13.8 VDC |
| Overcharge Protection |
15 VDC |
| Battery Type |
Lithium and Lead-acid |
| HMI |
LCD |
| Interface |
RS485 / USB |
| Monitoring |
N/A |
| Ingress Protection |
IP20 |
| Operating Temperature |
-10°C ~ 50°C |
| Humidity |
5% ~ 95% (Non-condensing) |
| Storage Temperature |
-15°C ~ 60°C |
| Net Weight |
3.6 kg |
| Dimensions |
330 × 226 × 92 mm (without bracket) |
| Max Operating Altitude |
4000 m (Derating above 1000 m) |
